Mini Size Laser Engraving Machine
Item No.: SST-M-003
- Fast speed
- Small volume
- Light weight
Fiber laser marking machine adopts MOPA fiber laser. It is an advanced equipment integrated of high-speed scanning galvanometer systems and superior control board.
Fan-cooled, compact machine.
High quality of output beam, high reliability, long life, maintenance-free.
Meet higher demand areas of marking depth, smoothness and fineness.
Customized worktable available according to marking object.
Laser power: 20W/30W/50W
Laser wavelength: 1064nm
Laser source: IPG&MAX
Q-switch frequency : 20KHZ-100KHZ
Optical quality: M2≤1.4
Marking field: 100*100mm/175*175mm
Minimum line width: 0.01mm
Minimum character: 0.1mm
Marking speed : 0~7000m/s
Cooling system : Air cooling
Repeat accuracy :0.01mm
Input power : AC 220V±22V 50Hz/60Hz 10A
lifetime :100,000hours(if properly operated)
Machine size: 530*420*560mm
Machine weight: 45kg
